Stanley C Dawson

US Patent:

45486611, Oct 22, 1985

Filed:

May 6, 1982

Appl. No.:

6/375640

Inventors:

Edward A. Escallier - Norwalk CA
Stanley R. Dawson - Corona CA
Joseph M. Shaheen - La Habra CA

Assignee:

The United States of America as represented by the Secretary of the Air
Force - Washington DC

International Classification:

H01B 1308

US Classification:

156 52

Abstract:

A multiconductor flat cable incorporates an approximately right angle turn in its conductor runs. The right angle turn is provided by first securing the conductor runs in a desired spacing through a first lamination of insulation cover and base sheets while leaving portions of the conductor runs exposed through a window in the first lamination. The first lamination is then severed at the lateral edges of the window so that an end portion of the first lamination may be moved ninety degrees relative to a remaining body portion thereto. The right angle turn is then secured by forming a second lamination with cover and base layers so as to overlap the first lamination and the turn in the conductor runs.

US Patent:

45019290, Feb 26, 1985

Filed:

Mar 7, 1984

Appl. No.:

6/586953

Inventors:

Edward A. Escallier - Norwalk CA
Stanley R. Dawson - Corona CA
Joseph M. Shaheen - La Habra CA

Assignee:

The United States of America as represented by the Secretary of the Air
Force - Washington DC

International Classification:

H01B 708

US Classification:

174117F

Abstract:

A multiconductor flat cable incorporates an approximately right angle turn in its conductor runs. The right angle turn is provided by first securing the conductor runs in a desired spacing through a first lamination of insulation cover and base sheets while leaving portions of the conductor runs exposed through a window in the first lamination. The first lamination is then severed at the lateral edges of the window so that an end portion of the first lamination may be moved ninety degrees relative to a remaining body portion thereto. The right angle turn is then secured by forming a second lamination with cover and base layers so as to overlap the first lamination and the turn in the conductor runs.
