Harold E Patterson

US Patent:

6415913, Jul 9, 2002

Filed:

Mar 17, 1997

Appl. No.:

08/819234

Inventors:

Paul I. Sleppy - Penn Run PA
Harold E. Patterson - Indiana PA

Assignee:

FMC Technologies, Inc. - Chicago IL

International Classification:

B65G 2716

US Classification:

198766, 1987521, 4145257

Abstract:

A base excited vibratory trough conveyor includes a trough mounted on leaf springs to a base which is excited by a linear vibratory drive. The vibratory drive produces a linear force which is oriented to be perpendicular to the springs, and the linear force is adjusted to equal the reaction force of the springs on the base during the desired stroke. Such balancing results in no stroke or movement of the base. A more lightweight base can thus be used without requiring that the base center of gravity be aligned along the center of gravity of the conveyor and the trough, or that the base be excessively heavy.

US Patent:

6659267, Dec 9, 2003

Filed:

Nov 5, 2001

Appl. No.:

10/007843

Inventors:

Harold E. Patterson - Indiana PA

Assignee:

FMC Technologies, Inc. - Chicago IL

International Classification:

B65G 2700

US Classification:

198771, 198760, 198766, 198770

Abstract:

A vibratory conveying device comprise an elongated trough for transporting materials, and a base underlying the trough. A plurality of elongated leaf springs support the trough on the base, with a vibratory drive system operatively connected to the base for effecting vibratory movement of the trough. Economical manufacture and efficient maintenance are facilitated by configuring the base so that it comprises a pair of sheet-like base side members, with a laterally extending drive support member extending therebetween. In the preferred form, the drive support member is detachably connected to the base side members with suitable mechanical fasteners. In turn, a pair of rotary vibratory drives of the drive system are removably mounted on respective opposite sides of the drive support member by a plurality of threaded mechanical fasteners.

US Patent:

6997134, Feb 14, 2006

Filed:

Feb 5, 2003

Appl. No.:

10/359023

Inventors:

Robert Phillip Bayus - Bellevue OH, US
David Alan Bailey - Indiana PA, US
Ramesh M. Gunawardena - Chagrin Falls OH, US
Michael Miller - Huron OH, US
Harold Eugene Patterson - Indiana PA, US

Assignee:

FMC Technologies Inc. - Chicago IL

International Classification:

B05C 19/06

US Classification:

118 13, 118 19, 118603, 118610, 99494

Abstract:

A drum breader and coating recirculation system that includes a spreader positioned at an end of the drum, the spreader having a plurality of angled surfaces to distribute coatings evenly; a screening platform positioned downstream of the spreader having a drive device for imparting straight-line angular displacement to the screening platform; and a drum feed conveyor positioned downstream of the screening platform, the drum feed conveyor having a belt extending at least partially along an upward angle.

US Patent:

7216757, May 15, 2007

Filed:

Dec 15, 2005

Appl. No.:

11/303701

Inventors:

Harold E. Patterson - Indiana PA, US
Paul Sleppy - Penn Run PA, US
Larry D. Martin - Lake Oswego OR, US

Assignee:

FMC Technologies, Inc. - Houston TX

International Classification:

B65G 25/04

US Classification:

1987508, 198764

Abstract:

A differential motion conveyor () for conveying products along an elongated trough structure () supported for reciprocal movement relative to a counterweight base structure () of a weight significantly greater than the weight of the trough structure. A rotational actuator () moving in a singular direction reciprocates the trough structure lengthwise relative and counterweighed base structure at a substantially continually varying velocity of the actuator to achieve a desired differential acceleration rate of the trough structure between the two opposing directions of longitudinal movement of the trough structure.

US Patent:

7866459, Jan 11, 2011

Filed:

Apr 17, 2009

Appl. No.:

12/426041

Inventors:

Harold E. Patterson - Indiana PA, US
Nathan Davis - Tigard OR, US
Scott Kuhnert - Portland OR, US

Assignee:

PPM Technologies, Inc. - Newberg OR

International Classification:

B65G 19/28

US Classification:

1987354, 1988604

Abstract:

The present disclosure provides a slide gate for use in conveyor systems that include permanent magnets to hold slide gate components in place relative to a conveyor trough , while allowing the slide gate to slide between open and closed positions relative to an opening or cutout formed in the conveyor floor. The slide gate is controllably opened and closed by an actuator system and can be magnetically attached to the actuator system such that the slide gate is attached to the conveyor system entirely through magnetic force. Magnetic attachment of the slide gate provides improved performance, ease of cleaning, and safety compared to known slide gate systems.

US Patent:

52939871, Mar 15, 1994

Filed:

Feb 21, 1992

Appl. No.:

7/839848

Inventors:

Kenneth M. Marshall - Indiana PA
Harold E. Patterson - Indiana PA
Paul I. Sleppy - Penn Run PA
Arthur L. Dean - Indiana PA

Assignee:

FMC Corporation - Chicago IL

International Classification:

B65G 2724

US Classification:

198769

Abstract:

An electromagnetic exciter for use in powering vibratory equipment includes a plurality of deflectable elastomeric springs in a configuration that allows the spring system to achieve a vertical non-linear spring rate increase beneficial in dual mass electromagnetic feeder and conveyor systems.

US Patent:

6019216, Feb 1, 2000

Filed:

Mar 27, 1997

Appl. No.:

8/826464

Inventors:

Harold E. Patterson - Indiana PA

Assignee:

FMC Corporation - Chicago IL

International Classification:

B65G 2700

US Classification:

1987521

Abstract:

A spring support bracket for supporting a sheet metal trough intermittently on leaf springs provides an L-shaped bracket for a welding connection to a side wall and bottom wall of the sheet metal trough and a spring block extending outwardly from the vertical member of the L-shaped bracket and tilted to the vertical rearwardly of the trough. The spring block includes an aperture for receiving a fastener for connecting a leaf spring thereto so that the trough may be supported by a plurality of leaf springs arranged intermittently along the length of the trough and on opposite lateral sides of the troughs.

US Patent:

55269214, Jun 18, 1996

Filed:

Mar 16, 1993

Appl. No.:

8/032468

Inventors:

Robert J. Kovalak - Homer City PA
Harold E. Patterson - Indiana PA
Paul I. Sleppy - Penn Run PA

Assignee:

FMC Corporation - Chicago IL

International Classification:

B65G 4740

US Classification:

198706

Abstract:

A bucket elevator system capable of being driven bi-directionally. The system having a plurality of pivoted buckets supported between two endless chains. Each bucket having a primary guide boss with an upper surface and a guide surface thereon. Guides arranged to contact the upper surface of the primary guide boll to restrain the pivotal movement of the buckets.
